Products • 163206
163206
The Non-Insulated Solderless Ring has a serrated barrel for greater wire retention and pullout strength.
Downloads
163206 INFO
Last Updated: 06/09/2022
Specification Details
| Parts per Unit | 100, 1000, 25, 50 |
|---|---|
| Features | 3 part construction contains: inner lug, additional copper sleeve for added strength, crimpability and seamless outer nylon cover, Designed for heavy-duty applications to resist vibration and moisture, Serrated barrel for greater wire retention/ pullout strength, Tin plated annealed copper for improved corrosion resistance, max conductivity and crimp strength |
| Application | Harsh |
| Gauge | 14, 16 |
| Insulation Color | Blue |
| Insulation Material | Nylon |
| Maximum Voltage | 600 V |
| Pack Type | Bag |
| Plating Material | Tin |
| SAE | No |
| Stud/Tab Size | 5/16 in |
| Subject to Prop 65 | No |
| Termination Material | Copper |
| Termination Method | Crimp |
| UL / CSA | No |
| Works With | Primary Wire |
| Brand | Not branded |
| Color | Blue |
| Product Length | 1.09 in |
| Product Width | 0.47 in |
| Product Type | Nylon Ring Double Crimp |
| RoHS Compliant | Yes |
| SKU | 163206, 163206-025, 163206-050, 163206-100, 163206-1000 |
| Product Height | 0.20 in |
| Product Weight | 0.002 lb |
| Country of Origin | Taiwan |
