164272
WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) and Lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Specification Details
| Parts per Unit | 10, 100, 25 |
|---|---|
| Features | 3 part construction contains: inner lug, additional copper sleeve for added strength, crimpability and seamless outer nylon cover, Designed for heavy-duty applications to resist vibration and moisture, For harsh applications rated 600V, Premium Nylon Double Crimp Terminals, Serrated barrel for greater wire retention/ pullout strength |
| Product Height | 0.24 in |
| Connector Gender | Male Bullet |
| SKU | 164272, 164272-025, 164272-100, 164272-2010 |
| RoHS Compliant | Yes |
| Product Type | Solderless Terminal |
| Product Width | 0.20 in |
| Product Length | 1.30 in |
| Color | Blue |
| Brand | GARDIAN |
| Works With | Primary Wire |
| UL / CSA | No |
| Termination Method | Crimp |
| Termination Material | Copper |
| Subject to Prop 65 | No |
| Stud/Tab Size | 0.195 in |
| SAE | No |
| Plating Material | Tin |
| Pack Type | Bag |
| Maximum Voltage | 600 V |
| Insulation Material | Heat Shrink |
| Insulation Color | Blue |
| Gauge | 14, 16 |
| Application | heavy duty applications |
| Product Weight | 0.002 lb |
| Country of Origin | Taiwan |
