200505
WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) and Lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Specification Details
| Parts per Unit | 100, 25, 50 |
|---|---|
| Features | Enhanced oil, fuel and acid resistance, Fine-stranded copper conductor, tin-plated, for maximum conductivity, flexibility and corrosion resistance, Highly abrasion-resistant, UL listed BC-5W2 boat cable |
| Cable Length | 100 ft, 25 ft, 50 ft |
| SKU | 200505, 200505-025, 200505-050, 200505-100 |
| RoHS Compliant | No |
| Product Width | 10.25 in, 12.00 in, 14.50 in |
| Product Length | 10.25 in, 12.00 in, 14.50 in |
| Color | Black |
| Cable Nominal Outer Diameter | 0.521 in |
| Brand | Not branded |
| Conductor Plating Material | Tinned |
| Works With | Copper Connectors |
| Voltage | 600 V |
| UL / CSA | Yes |
| Temperature Range (°F) | dry 221°F, wet 193°F |
| Temperature Range (°C) | dry 105°C, wet 75°C |
| Subject to Prop 65 | Yes |
| Strand Gauge | 30 |
| Strand Count | 833 |
| SAE | No |
| Prop 65 Item | DEHP, DINP |
| Pack Type | Roll |
| Insulation Thickness | 0.08 in |
| Insulation Material | PVC |
| Insulation Color | Black |
| Cable Nominal Outer Diameter | |
| Conductor Material | Copper |
| Gauge | 1 |
| Application | Marine |
| Product Weight | 15.00 lb, 30.00 lb, 7.50 lb |
| Country of Origin | USA |
