205605
WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) and Lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Downloads
Specification Details
| Parts per Unit | 25 |
|---|---|
| Features | Copper conductor for maximum conductivity, Designed for 6V or 8V batteries in 24, 36 and 48 volt systems, Exceeds SAE J163 conductivity standards, Only battery connectors that are UL and CUL listed, Special PVC insulations resists corrosion from battery acid |
| Product Height | 0.54 in |
| Assembly Cable Length | 20.00 in |
| SKU | 205605, 205605-025 |
| Works With | Golf Carts |
| Termination Material Plating | Tin |
| Strand Count | 43 |
| RoHS Compliant | Yes |
| Product Length | 20.00 in |
| Color | Red |
| Cable Nominal Outer Diameter | 0.30 in |
| Brand | Not branded |
| UL / CSA | No |
| Thimble | No |
| Termination Material Plating | |
| Termination Material | Copper |
| Temperature Range (°F) | -58 to 221°F |
| Temperature Range (°C) | -50 to 105°C |
| Subject to Prop 65 | No |
| Stud Hole Size | 5/16 in |
| SAE | Yes |
| Pack Type | Box |
| Insulation Thickness | 0.04 in |
| Insulation Material | PVC |
| Cable Nominal Outer Diameter | |
| Connection Type | Lug to Lug |
| Gauge | 6 |
| Application | Golf Carts |
| Product Weight | 0.19 lb |
| Country of Origin | China |
