230000
WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) and Lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Specification Details
| Parts per Unit | 100, 1000 |
|---|---|
| Features | Copper stranded conductor for maximum conductivity, For use at 60V or less, Meets or exceeds SAE J1128, PVC insulation resists abrasion, fuel, oil, acid and salt |
| Cable Length | 100 ft, 1000 ft |
| SKU | 230000, 230000-100, 230000-1000 |
| RoHS Compliant | Yes |
| Product Width | 3.50 in, 6.44 in |
| Product Length | 3.50 in, 6.44 in |
| Color | Black |
| Cable Nominal Outer Diameter | 0.084 in |
| Brand | Not branded |
| Works With | Automotive Connections |
| Voltage | 60 V |
| UL / CSA | No |
| Temperature Range (°F) | -40 to 176°F |
| Temperature Range (°C) | -40 to 80°C |
| Subject to Prop 65 | Yes |
| Strand Gauge | 28 |
| Strand Count | 7 |
| SAE | J1128 |
| Prop 65 Item | DEHP, DINP |
| Pack Type | Roll |
| Insulation Thickness | 0.023 in |
| Insulation Material | PVC |
| Cable Nominal Outer Diameter | |
| Conductor Material | Copper |
| Gauge | 22 |
| Application | General Purpose |
| Product Weight | 0.75 lb, 7.00 lb |
| Country of Origin | USA |
