Products • 4902F
4902F
Our Quick® Stud Terminal Locking Battery Connector is stackable, with 24-position anti-rotation teeth that bite into the lead for positive hold. It allows for connectors of different cable gauges to be mixed for maximum application and layout flexibility.
Downloads
4902F INFO
Last Updated: 06/09/2022
Specification Details
| Parts per Unit | 5, 50 |
|---|---|
| Features | Copper alloy, tin plated for added conductivity and corrosion resistance, Exceeds SAE standards, J163 and J1811, For crimp or solder applications, For preassembled cable options – see QuickLinks, Made in USA, Precise dimensions to fit battery posts for maximum contact, Quick Connectors are listed by UL® (UL® STD 486A) & CUL , when applied with Quick Cable Quick Crimp tools |
| Application | Heavy Duty |
| Gauge | 2 |
| Pack Type | Bag |
| Plating Material | Tin |
| SAE | J163, J1811 |
| Stud Hole Size | 3/8 in |
| Subject to Prop 65 | No |
| Termination Material | Copper |
| Termination Method | Crimp |
| UL / CSA | Yes |
| Works With | Side Posts |
| Brand | QUICK |
| Color | Silver |
| Product Length | 2.00 in |
| Product Width | 0.75 in |
| Product Type | Straight lug |
| Production Process | Cast |
| RoHS Compliant | Yes |
| SKU | 4902-005F, 4902-050F, 4902F |
| Product Height | 0.50 in |
| Product Weight | 0.06 lb |
| Country of Origin | USA |
