7626
Specification Details
| Parts per Unit | 1, 25 |
|---|---|
| Features | 2/0 GA fine-stranded copper conductor for maximum conductivity and flexibility, Connection sealed with MagnaTube™ heat-shrink, Made for truck, farm, construction, automotive and similar equipment, Meets or exceeds SAE and OEM specifications, Premium quality synthetic rubber insulated welding cable enables easy routing and cold weather flexibility, Temperature range: 221°F (105°C) to -58°F (-50°C) Welding Cable |
| Application | Construction, Farm, Trucks |
| Gauge | 2/0 |
| Connection Type | Lug to Lug |
| Insulation Material | EPDM |
| Insulation Thickness | 0.08 in |
| Pack Type | Bag, Box |
| Polarity | Positive |
| Prop 65 Item | DEHP, DINP, Lead |
| SAE | Yes |
| Strand Count | 1254 |
| Stud Hole Size | 3/8 in |
| Subject to Prop 65 | Yes |
| Temperature Range (°C) | -50 to 105°C |
| Temperature Range (°F) | -58 to 221°F |
| Termination Material | Copper |
| Termination Material Plating | |
| Thimble | No |
| UL / CSA | No |
| Works With | 12 V, 6 V |
| Brand | QuickLinks |
| Color | Red |
| Product Length | 8.75 in |
| Product Type | QuickLinks Between Batteries |
| RoHS Compliant | Yes |
| Termination Material Plating | Tin |
| SKU | 7626, 7626-001P, 7626-025P |
| Assembly Cable Length | 8.50 in |
| Product Weight | 0.45 lb |
| Terminal Material Plating | Tin |
| Country of Origin | USA |
